For alcohol oil burners, oil furnaces, and industrial heating equipment, a stable and reliable ignition system like our alcohol oil igniter is essential for proper equipment operation.
Our alcohol oil igniter uses high-voltage discharge technology, with approximately 38KV output driving the ceramic ignition rod to rapidly heat up to 1400℃ within about 10 seconds, achieving fast and stable fuel ignition.
Compared with traditional ignition methods, this fuel burner igniter provides faster heating speed, longer service life, and more reliable ignition performance.
Alcohol Oil Igniter Product Advantage
1.38KV High Voltage Ignition Output
The 220V AC fuel-burner-igniter input is converted into approximately 38KV high voltage output, providing strong ignition energy for alcohol fuel, methanol fuel, diesel oil and other liquid fuels.
2.Fast Heating Ceramic Ignition Rod
Fitted with heat-resistant ceramic ignition components, the rod reaches 1400°C within approximately 10 seconds after startup. Key strengths: Quick response, outstanding heat resistance, long service lifespan and consistent ignition.
3.Built-in 30-Second Automatic Ignition Control
Built-in 30-second Automatic Ignition Control A timing ignition circuit is integrated inside. Upon activation, the igniter runs continuously for 30 seconds and cuts off automatically once ignition succeeds. This boosts equipment safety while lowering power consumption.
4.Energy Efficient 35W Design
Energy-Saving 35W Design Rated at merely 35W, the unit maintains powerful ignition capacity whilst keeping energy consumption low.
Working Principle
Power supply connected (220V AC)
High voltage module generates approximately 38KV ignition voltage
Ceramic ignition rod heats up to 1400℃
Ignites alcohol fuel or oil-air mixture
Automatic shutdown after 30 seconds
Technical Specifications
| Product Specification | Specification |
|---|---|
| Product Name | Alcohol Oil Igniter / Oil Burner Igniter |
| Input Voltage | 220V AC |
| Output Voltage | Approx. 38KV |
| Power | 40W |
| Heating Temperature | Up to 1400℃ |
| Heat-up Time | Around 10 seconds |
| Ignition Duration | 30 seconds automatic stop |
| Ignition Mode | High Voltage Ceramic Ignition |
| Customization Available | Voltage, size, ignition time available |
Applications of Alcohol Oil Igniter
Alcohol Fuel Equipment:
Alcohol oil furnaces, methanol burners, ethanol combustion equipment.
Oil Burner Systems:
Oil furnaces, diesel burners, industrial combustion units Industrial Heating: Hot air furnaces, heating equipment, drying machines, industrial furnaces Custom Solutions: OEM burner supporting parts, automated heating systems, special ignition equipment.
Custom Ignition Solutions
Different combustion equipment requires different ignition voltages, ceramic rod dimensions, and control logic. We provide:
Customized ignition voltage
Customized ceramic rod length
Customized timer control
Customized connector and cable
We offer tailored ignition solutions based on your burner configuration.
